User Manual
Battery-powered screwdriver, 3.6 V with LED
- 4 -
Goobay
®
by Wentronic GmbH | Pillmannstraße 12
38112 Braunschweig | Germany
REV2019-01-03
V2.0tf
Original User Manual: German version
10 Specications
Article number 71880
Environmental conditions -5~+40 °C, max. 95 % RH
Battery-powered screwdriver
Connectors DC socket (2.1 x 5.5 mm)
input 5.5 V
, 0.6 A
Battery Li-Ion, 3.6 V, 1300 mAh
Working time max. ~45 Min.
Charging time 3-5 hrs
Emission sound pressure level 66.5 / 77.5 ± 3 dB(A)
Vibration level 0.814 ± 0.15 m/s²
No-load rotation 230
-1
Dimensions 220 x 70 x 45 mm / 175 x 150 x 45 mm
Weight 0.400 kg
Power supply unit
Connectors EURO plug, DC plug 5.5 x 2.1 mm
Input 100-240 V~ 50/60 Hz 0.3 A
output 5.5 V
, 0.6 A
Polarity
positive
Protection class 2
Cable length ~1.8 m
Dimensions 78 x 55 x 22 mm
Weight 170 g
Bits
CRV-PH1
CRV-PH2
CRV-1/4“
HSS-5/64“ (2,0 mm)
HSS-3/32“ (2,5 mm)
Extension 60 mm
Ta b . 2 : Specications
11 Maintenance and Cleaning
The products are maintenance-free.
Material damage
• Separate the product from mains.
• Clean only with a dry, soft cloth.
• Do not use cleaning agents and chemicals.
• Store cool and dry.
• Store the product out the reach of children and in a dry and
dust-protected ambience when not in use.
• Keep and use the original packaging for transport.
12 Liability notice
We reserve the right to printing errors and changes to product, packaging
or product documentation.
• See our terms of warranty. These are available in their current
form under the given contact details.
13 Disposal Notes
13.1 Device
According to the European WEEE directive, electrical and electronic
equipment must not be disposed with consumers waste. Its components
must be recycled or disposed apart from each other. Otherwise contami
native and hazardous substances can pollute our environment.
As a consumer, you are committed by law to dispose electrical and electronic de-
vices to the producer, the dealer, or public collecting points at the end of the devices
lifetime for free. Particulars are regulated in national right. The symbol on the pro-
duct, in the user`s manual, or at the packaging alludes to these terms. With this kind
of waste separation, application, and waste disposal of used devices you achieve an
important share to environmental protection.
WEEE No: 82898622
13.2 (Rechargeable) Batteries
(Rechargeable) batteries must not be disposed of with household waste. Their com-
ponents have to be supplied separately to the recycling or disposal, because toxic
and dangerous ingredients can harm the environment if not disposed of sustainably.
As a consumer, you are obliged to return them at the end of their service lives to the
manufacturer, the sales outlet or established for this purpose, public collection points
for free. Details regulates the respective country‘s law. The symbol on the product,
the instruction manual and / or the packaging draws attention to those provisions.
With this kind of material separation, recovery and disposal of waste (rechargeable)
batteries you make an important contribution to protecting our environment.
D-34000-1998-0099
14 EU Declaration of Conformity
The Wentronic GmbH, Pillmannstraße 12, 38112 Braunschweig, Germany
hereby declares with sole responsibility that the product mentioned
coincideswiththefollowingdirectives,standardsand/orspecications.
Any unauthorized changes to the product/s will void the validity of this
declaration.
Product/Device Type: 71880 Akkuschrauber
Supplier Code: 923
including accessories: PSU ICY0550-0600,
3 bits,
2 drills,
1 extension,
User manual
Applicable directives:
REACh 1907/2006/EC
Mach 2006/42/EC
ErP 2009/125/EC
RoHS 2011/65/EU
EMC 2014/30/EU
LVD 2014/35/EU
EN 60745-1 : 2009+A11: 2010
TR No.: SHES161000852801
EN 60745-2-2 : 2010
AfPS GS 2014 : 01 PAK
EG VO 278 : 2009
TR No.: XIB-16NO1812TTSP
EN 50563 : 2011
EN 50581 : 2012
EN 62321 : 2009
TR No.: XIB-16MY10-01CTSP-A0
EN 55014-1 : 2006+A1: 2009+A2: 2011
TR No.: 14712061 001, 14712061 002
EN 55014-2 : 1997+A1: 2001+A2: 2008
EN 61000-3-2 : 2014
TR No.: 64710150427901
EN 61000-3-3 : 2013
EN 60335-1 : 2012+A11: 2014
TR No.: 4840115057300, -EMF01
EN 60335-2-29 : 2004+A2: 2010
EN 62233 : 2008
Emission and radio disturbance
test distances: 3 m
Document maker: 130
Place and date: Braunschweig, 2017-08-16
Signature:
CEO - Marcus Wendt
