Quick Start Guide for
SATA to IDE converter
atricle no. 93583
ATTENTION! Read the instructions carefully and completely. It is part of the product and contains important notes for use. Keep this docu-
ment! This manual is a quick start guide. Find more information on enclosed CD-ROM and/or via www.wentronic.com as download version,
or by mail where applicable. Find the address at the bottom of the page, if available.
1 Safety Instructions:
ATTENTION! Only skilled electricians may assemble and disassemble the housing of the product.
DANGER! Risk of life by electric shock! Avoid contacting mains voltages!
ATTENTION! Risk of short-circuit! Never bridge contacts! Do not put things into slots or ports!
2 Description and Function:
This product is a connection kit to connect SATA or IDE HDDs with PCs‘ USB Interface.
It works with 3.5“ and 2.5“ Harddisks and HD drives and comes with cables and mains cable.
3 Connecting and Operating:
System requirements: Win 2000, XP, VISTA, 7, 8, 8.1, 10, Mac OS
USB 1.1 or 2.0 Interface
1. Please connect all cables like shown on the picture.
2. Connect the power cable to a 100-240 V AC mains socket.
3. Connect the USB cable with your computer.
4. It could take a few seconds till the hard disk will be shown on your desktop.
5. Now you have full access to the connected hard disk.
4 Warranty and Responsibility:
• As the manufacturer has no inuence on installation, warranty only applies to the product itself.
• The manufacturer is not liable for damages to persons or property caused by improper installation,
operation or maintenance.
• Do not alter or modify the product or its accessories.
• Any use other than described in this user`s manual is not permitted and causes loss of warranty,
loss of guarantee, and non-liability.
• We reserve our right for misprints and changes of the device, packing, or user`s manual.
5 Troubleshooting:
6 Disposal Instructions:
According to the European WEEE directive, electrical and electronic equipment must not be disposed with consumers waste. Its components must be recycled or disposed
apart from each other. Otherwise contaminative and hazardous substances can pollute our environment.
As a consumer, you are committed by law to dispose electrical and electronic devices to the producer, the dealer, or public collecting points at the end of the devices lifetime
for free. Particulars are regulated in national right. The symbol on the product, in the user`s manual, or at the packaging alludes to these terms. With this kind of waste
separation, application, and waste disposal of used devices you achieve an important share to environmental protection.
WEEE N
o
: 82898622
7 CE Declaration:
With the CE sign Goobay®, a registered trademark of the Wentronic GmbH ensures, that the product is conformed to the basic standards and directives.
8 Specications:
* The mentioned brands are the property of their respective owners and mentioned as reference only. Use of the product is at users own risk.
Revision Date: 2011-04-28
Version 1
Goobay®
by Wentronic GmbH
Pillmannstraße 12
38112 Braunschweig/Germany
no function Check all connections to be connected like described in chapter 3.
Ask a certied specialist.
operating systems Windows 2000, XP, VISTA, 7, 8, 8.1, 10, Mac OS
harddisk sizes 2.5“ & 3.5“ HDDs
input voltage 100-240 V AC 50/60 Hz
output voltage 5 V DC @ 2 A and 12 V DC @ 2 A
dimensions and weight 198 x 130 x 46 mm / 360 g
included in delivery mains cable, power supply, USB cable with IDE + SATA connection, power cable, SATA cable
