Goodman ARUF - AWUF Series Specifications (Part 1); AWUF Series Specifications (Part 2)

PRODUCT SPECIFICATIONS
28
AWUF[18-37]A*
AWUF18031**
AWUF18051 AWUF18081
AWUF24031**
AWUF24051 AWUF24081 AWUF24101
AWUF30031**
AWUF30051 AWUF30081 AWUF30101
Heating Capacity
Actual kW @ 240 volts 3.0 4.8 7.3 3.0 4.8 7.3 9.8 3.0 4.8 7.3 9.8
BTU/h @ 240 volts 10,240 16,390 24,925 10,240 16,390 24,925 33,460 10,240 16,390 24,925 33,460
Blower
Diameter 9" 9" 9" 10" 10" 10" 10" 9" 9" 9" 9"
Width 6"6"6"6"6"6"6"8"8"8"8"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 5/8" 5/8" 5/8" 5/8" 5/8" 5/8" 5/8" 3/4" 3/4" 3/4" 3/4"
Electrical Data
Min. Circuit Ampacity* 15.1/17.3 26.7/23.3 39.7/34.2 15.1/17.3 26.7/23.3 39.7/34.2 52.7/45.6 15.5/17.6 27.0/23.6 40.0/34.9 53.0/46.2
Max. Overcurrent Device (amps)* 20/20 30/30 40/40 20/20 30/30 40/40 60/50 20/20 30/25 40/35 60/50
Minimum VAC 197 197 197 197 197 197 197 197 197 197 197
Maximum VAC 253 253 253 253 253 253 253 253 253 253 253
Blower Motor
FLA 1.30 1.35 1.35 1.30 1.35 1.35 1.35 1.58 1.58 1.58 1.58
HP 1/5 1/5 1/5 1/5 1/5 1/5 1/5 1/3 1/3 1/3 1/3
Ship Weight (lbs)
84 84 84 84 84 84 84 93 93 93 93
* @ 240V/208V
AWUF310516 AWUF310816 AWUF321016
AWUF36051 AWUF36081 AWUF36101 AWUF37051 AWUF37081 AWUF37101
Heating Capacity
Actual kW @ 240 volts
4.8 7.3 9.8
4.8 7.3 9.8
4.8 7.3 9.8
BTU/h @ 240 volts 16,390 24,925 33,460 16,390 24,925 33,460 16,390 24,925 33,460
Blower
Diameter 10" 10" 10" 9" 9" 9" 10" 10" 10"
Width 8"8"8"8"8"8"8"8"8"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Electrical Data
Min. Circuit Ampacity* 30.1/26.8 43.1/38.1 56.2/49.4 27.0/23.6 40.0/34.9 53.0/46.2 30.1/26.8 43.1/38.1 56.2/49.4
Max. Overcurrent Device (amps)* 35/30 45/40 60/50 30/25 40/35 60/50 35/30 45/40 60/50
Minimum VAC 197 197 197 197 197 197 197 197 197
Maximum VAC 253 253 253 253 253 253 253 253 253
Blower Motor
FLA 4.1 4.1 4.1 1.58 1.58 1.58 4.1 4.1 4.1
HP
1/2 1/2 1/2
1/3 1/3 1/3
1/2 1/2 1/2
Ship Weight (lbs)
96 96 96
96 96 96
96 96 96
