Goodman ARUF - AWUF Series Specifications (16 B Models)

PRODUCT SPECIFICATIONS
29
AWUF[18-24]**16B*
AWUF180516B* AWUF180816B* AWUF240316B* AWUF240516B* AWUF240816B* AWUF241016B*
Heating Capacity
Actual kW @ 240 volts 4.8 7.3 3.0 4.8 7.3 9.8
BTU/h @ 240 volts 16,390 24,925 10,240 16,390 24,925 33,460
Blower
Diameter 9" 9" 10" 10" 10" 10"
Width 6" 6" 6"6"6"6"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 5/8" 5/8" 5/8" 5/8" 5/8" 5/8"
Electrical Data
Min. Circuit Ampacity* 26.6/23.3 39.6/34.6 15.1/17.3 26.7/23.3 39.7/34.2 52.7/45.6
Max. Overcurrent Device (amps)* 30/25 40/35 20/20 30/30 40/40 60/50
Minimum VAC 197 197 197 197 197 197
Maximum VAC 253 253 253 253 253 253
Blower Motor
FLA 1.30 1.30 1.30 1.35 1.35 1.35
HP 1/5 1/5 1/5 1/5 1/5 1/5
Ship Weight (lbs)
84 84 84 84 84 84
* @ 240V/208V
