Product Specifications
2 www.goodmanmfg.com SS-GSX13
SS-GSX13 www.goodmanmfg.com 3
GSX13
0181E*
GSX13
0241E*
GSX13
0301B*
GSX13
0361E*
GSX13
0421B*
GSX13
0481B*
GSX13
0601B*
GSX13
0611A*
Capacities
Nominal Cooling (BTU/h) 18,000 23,000 30,000 36,000 42,000 48,000 60,000 60,000
SEER / EER 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13/11
Decibels 75 75 73 74 75 76 77 72
Compressor
RLA 6.7 7.7 12.8 14.1 17.9 19.9 25.0 26.4
LRA 41 37 64 77 112 109 134 134
Condenser Fan Motor
Horsepower 1/8 1/8 1/8 1/4 1/4 1/4 1/4 1/4
FLA 0.7 0.7 0.7 1.5 1.5 1.5 1.5 1.5
Refrigeration System
Refrigerant Line Size ¹
Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Line Size (“O.D.) ¾" ¾" ¾" ⅞" 1⅛" 1⅛" 1⅛" ⅞"
Refrigerant Connecon Size
Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Valve Size (“O.D.) ⁴ ⁵ ¾" ¾" ¾" ¾" ⁴ ⅞" ⁵ ⅞" ⁵ ⅞" ⁵ ¾"
Valve Type Sweat Sweat Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 44 44 44 52 61 80 80 111
Shipped with Orice Size 0.051 0.055 0.061 0.070 0.076 0.080 0.086 0.086
Electrical Data
Voltage (60 Hz) 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Minimum Circuit Ampacity ² 9.1 10.3 16.7 19.1 23.9 26.4 32.8 34.5
Max. Overcurrent Protecon ³ 15 amps 15 amps 25 amps 30 amps 40 amps 45 amps 50 amps 60 amps
Min / Max Volts 197/253 197/253 197/253 197/253 197/253 197/253 197/253 197/253
Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾"
Equipment Weight (lbs) 102 103 115 118 171 175 184 211
Ship Weight (lbs) 117 120 132 135 189 193 202 233
¹ Line sizes denoted for 25’ line sets, tested and rated in accordance with AHRI Standard 210/240. For other line-set lengths or sizes, refer
to the installaon & Operang instrucons and/or the long line-set guidelines.
² Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes
³ Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
⁴ Installer will need to supply ¾” to ⅞” adapters for sucon line connecons.
⁵ Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.
