Goodman GSX13 - Page 6

6 www.goodmanmfg.com SS-GSX13
SS-GSX13 www.goodmanmfg.com 7
Expanded Cooling Data — GSX130241E* / CA*F3030*6D*
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
900
MBh 22.5 23.4 25.6 - 22.0 22.8 25.0 - 21.5 22.3 24.4 - 21.0 21.7 23.8 - 19.9 20.6 22.6 - 18.4 19.1 21.0 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.49 -
∆T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
kW 1.63 1.66 1.71 - 1.75 1.78 1.83 - 1.85 1.89 1.95 - 1.94 1.98 2.04 - 2.02 2.06 2.13 - 2.09 2.13 2.20 -
Amps 5.8 6.0 6.2 - 6.3 6.4 6.7 - 6.8 7.0 7.2 - 7.3 7.5 7.7 - 7.8 8.0 8.2 - 8.2 8.4 8.7 -
Hi PR 228 246 259 - 256 276 291 - 291 314 331 - 332 357 377 - 373 402 424 - 413 444 469 -
Lo PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 152 -
800
MBh 21.9 22.7 24.8 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 20.4 21.1 23.1 - 19.3 20.0 22.0 - 17.9 18.6 20.3 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
∆T 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
kW 1.62 1.65 1.70 - 1.73 1.77 1.82 - 1.84 1.87 1.93 - 1.93 1.97 2.03 - 2.00 2.05 2.11 - 2.07 2.11 2.18 -
Amps 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.8 6.9 7.2 - 7.2 7.4 7.7 - 7.7 7.9 8.1 - 8.2 8.4 8.6 -
Hi PR 226 243 257 - 254 273 288 - 288 310 328 - 329 354 373 - 370 398 420 - 408 440 464 -
Lo PR 104 111 121 - 110 117 127 - 114 121 132 - 120 127 139 - 126 134 146 - 130 138 151 -
700
MBh 20.2 20.9 22.9 - 19.7 20.4 22.4 - 19.3 20.0 21.9
- 18.8 19.5 21.3 - 17.8 18.5 20.3 - 16.5 17.1 18.8 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.77 0.64 0.45 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 14 11 -
kW 1.58 1.61 1.66 - 1.69 1.73 1.78 - 1.79 1.83 1.89 - 1.88 1.92 1.98 - 1.96 2.00 2.06 - 2.02 2.06 2.13 -
Amps 5.6
5.7 5.9 - 6.1 6.2 6.4 - 6.6 6.7 7.0 - 7.0 7.2 7.4 - 7.5 7.7 7.9 - 7.9 8.1 8.4 -
Hi PR 219 236 249 - 246 265 280 - 280 301 318 - 319 343 362 - 359 386 407 - 396 426 450 -
Lo PR 101 107 117 - 106 113 124 - 111 118 129 - 116 124 135 - 122 130 141 - 126 134 146 -
75
900
MBh 22.9 23.6 25.5 27.4 22.4 23.0 24.9 26.8 21.9 22.5 24.4 26.1 21.3 22.0 23.8 25.5 20.3 20.9 22.6 24.2 18.8 19.3 20.9 22.4
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.95 0.85 0.64 0.41 0.95 0.85 0.65 0.42
∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 18 17 14 10
kW 1.64 1.67 1.72 1.77 1.76 1.79 1.85 1.91 1.86 1.90 1.96 2.02 1.96 2.00 2.06 2.13 2.04 2.08 2.15 2.21 2.10 2.15 2.22 2.29
Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1
Hi PR 231 248 262 273 259 279 294 307 294 317 334 349 335 361 381 397 377 406 429 447 417 448 474 494
Lo PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164
800
MBh 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7 21.3 23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8
S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
∆T 20 19 15 11 20 19 15 11
21 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10
kW 1.63 1.66 1.71 1.76 1.75 1.78 1.84 1.89 1.85 1.89 1.95 2.01 1.94 1.98 2.04 2.11 2.02 2.06 2.13 2.20 2.09 2.13 2.20 2.27
Amps 5.8
6.0 6.2 6.4 6.3 6.4 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.7 8.0 7.8 8.0 8.2 8.5 8.2 8.4 8.7 9.1
Hi PR 228 246 260 271 256 276 291 304 291 314 331 345 332 357 377 393 373 402 424 443 413 444 469 489
Lo PR 105 112 122 130 111 118 129 137 115 123 134 143 121 129 141 150 127 135 147 157 131 140 152 162
700
MBh 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1 19.7 21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1
S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.54 0.34 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.88 0.78 0.59 0.38
∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
kW 1.59 1.62 1.67 1.72 1.71 1.74 1.79 1.85 1.81 1.84 1.90 1.96 1.90 1.94 2.00 2.06 1.97 2.01 2.08 2.14 2.04 2.08 2.15 2.22
Amps 5.7 5.8 6.0 6.2 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.3 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3 8.0 8.2 8.5 8.8
Hi PR 222 238 252 263 249 267 282 295 283 304 321 335 322 346 366 382 362 390 412 429 400 431 455 474
Lo PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and sucon service valves. kW = Total system power
