CONDENSING UNIT SPECIFICATIONS
5
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance with all national
and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice.
ALWAYS refer to the unit's serial plate for the most up-to-date general and electrical information.
GSX160181F* - GSX160361F*
*
Up to 24' in equivalent line length
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR
UNIT, NOT THE INDOOR COIL.
GSX160181FA GSX160241FA GSX160301FA GSX160361FA
Cooling Capacity, BTUH 18,000 24,000 30,000 36,000
Decibels 73.5 73.5 73.5 73.5
Compressor
R.L. Amps 9.0 13.5 12.8 14.1
L.R. Amps 46.0 58.3 64.0 77.0
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/6
F.L. Amps 1.10 1.10 1.10 1.10
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 7/8" 3/4" 3/4" 7/8"
Liquid Valve Connection, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Valve Connection, Inches O.D.* 7/8" 3/4" 3/4" 3/4"
Valve Connection Type Sweat Sweat Sweat Sweat
Refrigerant Charge 80.0 89.0 105.0 115.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
12.4 18.0 17.1 18.7
Maximum Overcurrent Device
(2)
20 30 30 30
Min/Max Volts 197 / 253 197 / 253 197 / 253 197 / 253
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 193 193 200 225
