SS-SSZ14 www.goodmanmfg.com 3
Product SPecificationS
SpeCifiCationS
SSZ14
0181A
SSZ14
0241A
SSZ14
0301A
SSZ14
0361B
SSZ14
0381A
SSZ14
0421A
SSZ14
0481A
SSZ14
0601A
Nominal Capacities
Cooling (BTU/h) 18,000 24,000 30,000 36,000 36,000 42,000 48,000 60,000
Heang (BTU/h) 18,000 24,000 30,000 36,000 36,000 42,000 48,000 60,000
Decibels 70 72 72 74 74 73 74 75
Compressor
RLA 9.0 12.8 14.1 14.1 14.1 17.9 19.9 26.4
LRA 48.0 58.3 73.0 77.0 77 112.0 109.0 134.0
Condenser Fan Motor
Horsepower 1/12 1/6 1/6 ¼ 1/6 ¼ ¼ ¼
FLA 0.6 1.1 1.0 1.5 1 1.5 1.5 1.5
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Line Size (“O.D.) ¾" ¾" ¾" ⅞" ⅞" 1⅛" 1⅛" 1⅛"
Refrigerant Connecon Size
Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Valve Size (“O.D.) ¾" ¾" ¾" ¾" ⅞" ⅞" ⅞" ⅞"
Valve Connecon Type Sweat Sweat Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 140 160 185 186 211 210 270 275
Electrical Data
Volts-Phase (60 Hz) 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1
Minimum Circuit Ampacity ² 11.9 17.1 18.6 19.1 19.0 23.9 26.4 34.5
Max. Overcurrent Protecon ³ 20 25 30 30 30 40 45 60
Min / Max Volts 197 / 253 197 / 253 197 / 253 197 / 253 197/253 197 / 253 197 / 253 197 / 253
Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾"
Equipment Weight (lbs) 173 183 185 192 253 246 278 292
Ship Weight (lbs) 191 201 203 210 275 268 300 314
¹ Tested and rated in accordance with AHRI Standard 210/240
² Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes
³ Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the rang plate for electrical data on the unit being installed.
• Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.
• Installaon of these units requires the specied TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT
NOT THE INDOOR COIL.
