Goodwe ES Series - User Manual

Other manuals for Goodwe ES Series

Quick Installation Guide19 pages

Quick Start Guide9 pages

Questions and Answers

D
davidfloresSep 14, 2025
What does internal comm loss mean on Goodwe Inverter?
- J
  Jordan MendezSep 14, 2025
  An 'Internal Comm Loss' error on your Goodwe Inverter can be caused by several issues, including frame format errors, parity checking errors, CAN bus offline problems, hardware CRC errors, incorrect send/receive control bit settings, or transmitting to a unit that is not allowed. Disconnect the AC output switch and DC input switch, then connect them again after 5 minutes. If the problem persists, contact the dealer or the after-sales service.
C
Crystal EricksonAug 25, 2025
How to fix 'Low Insulation Res.' error on my Goodwe ES Inverter?
- K
  Karen BirdAug 25, 2025
  A 'Low Insulation Res.' error on your Goodwe Inverter indicates that the PV string is short-circuited to PE, or the PV system is in a moist environment with the cable not well insulated to the ground. Check if the resistance of the PV string to PE exceeds 50kΩ; if not, check for a short circuit point. Also, ensure the PE cable is correctly connected. If the resistance is lower on rainy days, reset the ISO.
C
Cindy WarrenAug 25, 2025
What causes Grid Overvoltage on a Goodwe Inverter and how to fix it?
- T
  Tonya OwenAug 26, 2025
  A Grid Overvoltage error on your Goodwe Inverter occurs when the grid voltage exceeds the permissible range, or the duration of high voltage exceeds the requirement of HVRT. If this problem occurs occasionally, the utility grid may be temporarily abnormal, and the inverter will recover automatically once the grid returns to normal. If the problem occurs frequently, check whether the grid voltage is within the permissible range. If it exceeds the limit, contact your local power company. If the grid frequency is within range, you can modify the overvoltage protection threshold, HVRT, or disable the overvoltage protection function after obtaining consent from the local power company. Also, check that the AC breaker and output cables are securely and correctly connected.
M
Monica SmithNov 25, 2025
Why is my Goodwe ES Inverter showing a Grid Undervoltage error?
- V
  vancechristopherNov 25, 2025
  A Grid Undervoltage error on your Goodwe Inverter means that the grid voltage is lower than the permissible range, or the duration of low voltage exceeds the requirement of LVRT. If the problem occurs occasionally, it may be due to a temporary issue with the utility grid, and the inverter should recover automatically when the grid returns to normal. If the problem occurs frequently, verify that the grid voltage is within the permissible range and contact the local power company if it isn't. If the grid frequency is within range, you might need to modify the undervoltage protection threshold, LVRT, or disable the undervoltage protection function, but only after getting approval from the local power company. Also, check whether the AC breaker and the output cables are securely and correctly ...
P
Paula SotoSep 14, 2025
How to fix AC HCT Check abnormal on Goodwe ES Inverter?
- K
  kevin68Sep 14, 2025
  If your Goodwe Inverter is showing an 'AC HCT Check abnormal' error, it means that the sampling of the AC HCT is abnormal. Disconnect the AC output switch and DC input switch, then connect them again after 5 minutes. If the problem persists, contact the dealer or the after-sales service.
S
Scott LopezSep 23, 2025
Why Goodwe Inverter ES/Battery not charge when PV?P-load?
- T
  Tammy WhiteSep 23, 2025
  If the ES/Battery is not charging when PV?P-load, check the following: 1. Verify that the charge voltage is set correctly. 2. Confirm whether the settings are configured for charge time only. 3. Check if the battery is fully charged or if the battery voltage has reached the specified charge voltage.
M
Michael JohnsonSep 6, 2025
What to do if there is a utility loss with my Goodwe ES?
- W
  wandersonSep 6, 2025
  If you're experiencing a utility loss with your Goodwe Inverter, it could be due to a failure in the utility grid power. In this case, the alarm should clear automatically once the grid power is restored. Alternatively, the AC cable might be disconnected, or the AC breaker could be off. Ensure the AC cable is properly connected and the AC breaker is turned on.
A
andersonjesseSep 7, 2025
What to do if my Goodwe ES Inverter displays a grid rapid overvoltage error?
- X
  xnelsonSep 7, 2025
  A 'Grid Rapid Overvoltage' error on your Goodwe Inverter suggests that the grid voltage is either abnormal or ultra-high. If this happens occasionally, it might be a temporary issue with the utility grid, and the inverter should automatically recover when the grid returns to normal. If the problem occurs frequently, check whether the grid voltage is within the permissible range. If the grid voltage exceeds the permissible range, contact the local power company. If the grid voltage is within the permissible range, modify the grid overvoltage rapid protection threshold after obtaining the consent of the local power company.
S
sanfordshannonSep 23, 2025
What to do if Goodwe Inverter ES does not start up with ONLY PV connected?
- K
  Kyle WellsSep 23, 2025
  If the Goodwe Inverter ES does not start up with ONLY PV connected, make sure the voltage of PV is higher than 125V. If the voltage is OK, but the problem persists, contact GoodWe after-sales services.
N
natalie11Aug 31, 2025
What does Grid 10min Overvoltage mean on my Goodwe Inverter?
- D
  Derrick KirbyAug 31, 2025
  A Grid 10min Overvoltage error on your Goodwe Inverter indicates that the moving average of grid voltage in 10 minutes exceeds the range of safety requirements. If the problem occurs occasionally, the utility grid may be abnormal temporarily, and the inverter will recover automatically after the grid returns to normal. If the problem occurs frequently, check whether the grid voltage is within the permissible range. Contact the local power company if the grid voltage exceeds the permissible range. If the grid voltage is within the permissible range, modify the grid overvoltage rapid protection threshold after obtaining consent from the local power company.

Summary

Safety Instructions

General Safety

General safety guidelines and precautions for safe operation.

PV String Safety

Inverter Safety

Specific safety precautions for the inverter unit itself.

Battery Safety

Product Introduction

Application Scenarios

Working Modes

Key Functionalities

Installation Procedures

Installation Requirements

Environmental and site requirements for installation.

Inverter Installation

Step-by-step guide for mounting and installing the inverter.

Electrical Connections

Safety Precautions

Critical safety rules for electrical connections.

Connection Preparations

DC Input Cable Connection

Battery Cable Connection

Steps to connect battery cables securely.

AC Cable Connection

Equipment Commissioning

Pre-Power On Checks

Checklist before powering up the system.

Power On Procedure

Sequence of steps to safely power on the inverter.

System Configuration

Parameter Setup via App

System Monitoring

Maintenance and Troubleshooting

Power Off Procedure

Steps to safely turn off the inverter before maintenance.

Troubleshooting Guide

Common faults and their solutions.

Routine Maintenance

Technical Specifications

ES Inverter Specs

Detailed technical data for ES series inverters.

SBP Inverter Specs

Detailed technical data for SBP series inverters.

Goodwe ES Series Specifications

General

Type	Hybrid Inverter
Battery Voltage Range	40-60V
Number of MPPTs	2
Output Frequency	50/60Hz
Power Range	3kW - 6kW
Max AC Output Power	6 kW
Communication Interfaces	RS485
Output Voltage	230 V
Battery Voltage	48 V
Operating Temperature	-25°C to 60°C
