General:
Item Specifications
Power Supply AC 100 - 240V, 50 - 60Hz
Power Consumption 200 W (Max.)
130 W (Typ.)
<0.5W (standby mode)
Build version jam_kiosk_20170502-1700_RC06.155815817
Dimensions 1352(W) x 1817.4(H) x 1019.5(D) mm (Floor standing)
1352(W) x 978.7(H) x 211.5(D) mm (Wall mounted)
Weight 27.27Kg (Floor Standing)
6.85Kg (Wall mounted)
Gross Weight 69.5Kg
Tilt 0º~18º
In/Out Terminals
Item Specifications
SPDIF Output SPDIF Port Serial digital audio output when input is HDMI
RJ-45 RJ-45 Jack x 1 (8 Pin) 1000BaseT
HDMI Input HDMI Jack x 2
(Type A) (19 Pin)
Digital RGB:TMDS (Video + Audio)
MAX: Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA), 4K/2K 30/60Hz (HDMI2.0 only)
Audio - 48 KHz/ 2 Channel (L+R)
Separate to HDMI 1.4 and HDMI 2.0
USB Input USB x 2 (Type A) USB 3.0
USB Input USB x 1 (Type C) USB Type C@3A/storage/DP 1.2 input

Google jamboard Specifications

General

Display Size	55 inches
Processor	NVIDIA Jetson TX1
RAM	4 GB
Storage	16 GB
Audio	Built-in speakers
Resolution	4K UHD (3840 x 2160)
Connectivity	Wi-Fi, HDMI 2.0, USB Type-C, USB 3.0, Ethernet
Microphone	Built-in microphone
Stylus	Passive stylus
Built-in Apps	Google Workspace apps, Jamboard app
Mounting Options	Wall mount
Touch Technology	Capacitive touch
Camera	Wide-angle HD camera
