JP22
-
Connects T0CKI to 32.768 kHz external clock
JP23
1-2
Connects one side of piezo sounder to ground (other side connects to P1A)
2-3
Connects one side of piezo sounder to P1B (other side connects to P1A)
JP24
1-2
Connects 10 kΩ potentiometer to RA0 / CIN+ / C1IN+
2-3
Connects LDR1 to AN0 / CIN+ / C1IN+
JP25
1
Connects LDR2 to AN2
2
Connects LDR2 to C2IN+
3
Connects LDR2 to CIN- / C1IN-
JP26
1
Connects digital variable frequency signal to CCP1
2
Connects digital variable frequency signal to T1G
JP27
-
Connects sawtooth variable frequency signal to C2IN+
