OM-03645−OE05
April 17, 2000
Rev. B 04/10/01
ACE
THE GORMAN-RUPP COMPANY MANSFIELD, OHIO
GORMAN-RUPP OF CANADA LIMITED ST. THOMAS, ONTARIO, CANADA Printed in U.S.A.
Copyright by the Gorman-Rupp Company
INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL
WITH PARTS LIST
CE SERIES PUMP
MODEL
CE6A60−F4L

Questions and Answers

Summary

Safety - Section A

Operational Hazard Warnings

Details risks related to pump materials, lifting, connections, closed valves, and hot components.

Operation - Section C

General Operation Warnings and Priming Procedures

Covers critical safety warnings, basic operational advice, and detailed steps for pump priming.

Pump Performance Monitoring and Overheating

Covers leakage checks, liquid temperature limits, overheating causes, and strainer maintenance for optimal flow.

Troubleshooting - Section D

General Troubleshooting Safety and Pump Priming Issues

Includes safety steps before servicing and addresses common causes and remedies for pump priming failures.

Pump Performance and Flow Issues

Lists possible causes and remedies for the pump stopping or failing to deliver rated flow or pressure.

Pump Maintenance and Repair - Section E

Pump and Seal Disassembly and Reassembly

Covers the procedures for disassembling, inspecting, and reassembling the pump and its seals.

Pre-Disassembly Safety and Back Cover Removal

Outlines safety warnings before disassembly and procedures for removing the back cover and wear plate.

Impeller Loosening Procedure

Details the steps and precautions for loosening and removing the pump impeller.

Rotating Assembly and Impeller Removal

Explains how to remove the rotating assembly and then the impeller from the shaft.

Seal Removal Procedure

Provides instructions for carefully removing the seal components from the shaft and housing.

Shaft and Bearing Removal and Cleaning

Details procedures for removing, cleaning, and inspecting shaft and bearings, with safety cautions.

Shaft and Bearing Reassembly and Lubrication

Guides on heating/installing bearings, oil seals, and lubricating the intermediate.

Seal Reassembly and Installation

Details the process for reassembling and installing the seal components, with critical cautions.

Seal Component Installation and Cautions

Provides instructions for installing stationary and rotating seal elements, with cautions on seal reuse and temperature.

Impeller Installation and Adjustment

Guides on installing the impeller, adjusting shims for clearance, and ensuring proper thread cleanliness.

Lubrication: Seal Assembly and Bearings

Provides specific lubrication instructions for the seal assembly and pump bearings.
