8
Build Manual
BUILD AREA
Build the stand in front of the area you
intend to position Arc.
Ensure the ground is stable and level
and capable of supporting the oven’s
weight.
Don’t place any of the parts on an
abrasive surface and avoid damaging
the paintwork of the metal parts.
2ft 5⁄”
749mm
3ft 5⁄”
1042mm
3ft 10⁄”
1176mm
4ft 6⁄”
1376mm
3ft 8⁄”
1139mm
2ft 9⁄”
850mm
