22
24.9"
18.2"
7.9"
WARNING
When placing your oven it is important
to maintain proper clearances from
combustible construction. Ensure Dome
S1 has 1ft clearance (back and sides)
and 3ft 4” clearance (front) from any
combustible construction.
Under no circumstances is the oven
to be placed under or on top of any
combustible structure.
Always keep the area around the oven
clear of any combustible materials,
gasoline and other flammable vapors
and liquids.
When deciding where to place Dome
S1 ensure the area is large enough to
accommodate the oven with 2” (50mm)
around the base of the dock for air
intake. It is important nothing is blocking
the meshed panels as this will affect the
performance of Dome S1.
OVEN PLACEMENT
28.7”
24.7"
