Build Manual
What’s In The Box
16x
2x
2x
2x
4x
2x
6x
2x
4x
2x
2x
12x 1x 4x 8x 1x 4x 28x 8x 4x
BUILD AREA
Build the stand in front of the area you
intend to position Dome.
Ensure the ground is stable and level
and capable of supporting the oven’s
weight.
Don’t place any of the parts on an
abrasive surface and avoid damaging
the paintwork of the metal parts.
SCALE 1:1
F F F F F F F F F F
4ft 3⁄”
1334mm
2ft 8⁄”
880mm
2ft 5⁄”
775mm
3ft 2⁄”
997mm
4ft ⁄”
1227mm
5ft 4⁄”
1665mm
