4
WAVEFORMS
2. SERVO WAVEFORMS
SER
V
O
W
A
VEFORMS
(IC601-38) 2.6Vp-p
0.5V/0.1 sec/cm
REC/PLAY
(IC601-18) 5Vp-p
2V/5msec/cm
REC/PLAY
(IC601-77) 5Vp-p
sec/cm
REC/PLAY
(IC601-76) 5Vp-p
sec/cm
REC/PLAY
(IC601-94) 3Vp-p
1V/5msec/cm
REC
(IC601-97) 4.4Vp-p
1V/5msec/cm
PLAY
(IC601-90) 25Vp-p&5Vp-p
1V/5msec/cm
REC/PLAY
(IC601-87) 2.5Vp-p
1V/0.2msec/cm
REC/PLAY
14.
18.
22.
20. 21.
15. 16. 17.
