Grace NP-P15 - Page 8

8
Model NP-PS
Dimension (WxHxD) MM 439x900x487
Weight KG 80
Air inlet Pipe MM 50
Air outlet Pipe MM 80
Heat Area M2 60
Automatic Burning Time (Min-Max.) H 20/50
Fuel Wood Pellet
Consumption for Pellet (Min-Max) 0.4/0.9
Efficiency % 82%
Hopper Capacity KG 20
Electronic consumption W/H 100-400
Rating Voltage and Frequency V/HZ 230/50-115/60
Rating Power KW 5
Model NP-PI
Dimension (WxHxD) MM 471x993x470
Weight KG 110
Air inlet Pipe MM 50
Air outlet Pipe MM 80
Heat Area M2 90
Automatic Burning Time (Min-Max.) H 18/34
Fuel Wood Pellet
Consumption for Pellet (Min-Max) 0.7/1.4
Efficiency % 85%
Hopper Capacity KG 25
Electronic consumption W/H 100-400
Rating Voltage and Frequency V/HZ 230/50-115/60
Rating Power KW 8.0
