18 310310
Parts
Model 970024
Supply Unit with Pneumatic Low Level Shut–Off, 55:1 Ratio Bulldog Pump
Includes items 1–7
1
3
2
Ref No. 3 Fluid Supply Hose
Includes Items 4–7
7 6 5 4
Ref Part
No. No. Description Qty
Ref Part
No. No. Description Qty
1 C59523 PUMP, ram–mounted 200 liter (55 gal.)
See 308027 for parts 1
2 918478 KIT, shut–off, low level, pneumatic
See 310294 for parts 1
3 C56995 HOSE, fluid supply;
Includes items 4–7 1
4 521973 . HOSE ASSEMBLY 1
5 521975 . UNION, pipe 1
6 C20490 . NIPPLE, hex 1
7 118854 . VALVE, ball 1
To Next Page
