Graco EVO User Manual

14
{EN INSTRUCTIONS}
Opening Pushchair Frame – see page 3, images 1, 2, 3
Wheels – see page 3, images 4, 5, 6, 7, 8, 9
To Fold Pushchair without Toddler Seat– see page 3, images 10, 11
Unfolding Your Pushchair – see page 4, images 1, 2, 3
Swivel Wheel Lock – see page 4, images 4, 5
To Remove Front Wheels – see page 4, image 6
Brakes – see page 4, images 7, 8
To Attach and Remove Graco® Click Connect™ Infant Car Seat to/from pushchair frame - see page
5, images 1, 2, 3, 4
Attach/Remove Toddler Seat – see pages 5, 6, images 5, 6
Bumper Bar– see page 6, images 7, 8
Hood – see page 6, images 9, 10, 11
To Raise and Recline Seat – see page 6, images 12, 13
Adjusting Footrest – see page 7, image 1
Handle Height Adjustment – see page 7, image 2
To Fold Pushchair with Toddler Seat– see page 7, images 3, 4, 5
Securing Your Child – see page 7, images 6, 7, 8, 9, 10, 11
Adjusting Harness Height Position – see page 8, image 1, 2,3, 4, 5, 6
Using Raincover – see page 8, images 7, 8, 9, 10
Footmu – see page 9, images 1, 2, 3, 4, 5
Luxury Footmu – see page 10, images 1, 2, 3, 4, 5, 6

Graco EVO Specifications

General

Type	Traditional stroller
Foldable	Yes
Fold style	Flat
Wheels type	Solid wheels
Product color	Black, Grey
Number of seats	1 seat(s)
Maximum baby weight	15 kg
Minimum baby weight	0 kg
Recommended age (max)	36 month(s)
Recommended age (min)	0 month(s)
Number of front wheels	2
Number of recline positions	3
Stroller accessories included	Footmuff, Rain cover
Wheels mobility	Swivel

Weight and Dimensions

Depth	890 mm
Width	600 mm
Height	102 mm
Weight	6500 g
Folded depth	410 mm
Folded height	106 mm
