22
LATCH
Connector
*
LATCH
Storage
United States Federal Motor Vehicle Safety Standards have defined a
system for installing car seats in vehicles. The system is called LATCH.
* LATCH may be used IN PLACE of vehicle belt ONLY if vehicle is
equipped with LATCH anchor points. Please refer to vehicle owner’s
manual for LATCH locations.
BASE
LATCH
Adjustment
Belt
Level indicator **
**Level
Indicator
The level indicator is attached to the side of
the base and indicates whether or
not the infant restraint is properly reclined.
Instruction
manual
storage
Knob for
Adjustable Foot
Adjustable Foot
