This car seat is for children: Forward-Facing: 22-65 lb (10-30 kg)
Booster: 30-100 lb (14-45 kg)
Adult Assembly Required
1. Raise Seat Back
Grab seat pad fabric in sitting area to
expose the gutters.
Make Sure all hands, fingers and other
objects are clear of the gutters.
Make Sure the harness straps are securely
attached within the “T”-shaped slots around
the arms as shown.
With your other hand, raise seat back so
that both arms LOCK into the gutters.
Arms should CLICK into the gutters. Seat
assembly should appear as shown.
Harness
Strap
T-Slot
Arm
Attach Head Support
Squeeze height adjust button and push head
support into slots on the back support as
shown. Head support will click into the back
support.
You may need to unfasten the hook and
loop attachment tape on both sides at the
top of the back support to allow for easier
access to the slots.
Always use child restraint with head
support installed and properly adjusted.
Click!
Car Seat Assembly (On Select Models)
(Follow the directions that matches your model)
