12
13
Pull on crotch strap to
be sure it is secured.
Insert NEW tongues
into buckle.
15
14
Insert metal
retainer from
NEW buckle into
crotch slot in the
seat pad and
seat bottom as
shown.
Top View Bottom View
Push button and
remove tongues from
the NEW buckle.
11
10
Reach under
seat to the metal
retainer. Push
the retainer up
through bottom of
seat and remove
buckle and
discard.
CLICK!
FINAL CHECK :
• Tug on the buckle to be sure
it is properly secured in the
bottom of the seat and does
not come out.
• MAKE SURE the harness
straps are not twisted.
• Make sure the chest clip is
properly threaded as shown
in Step 7.
Top View Bottom View
Any questions
please contact us at :
In USA: Graco Children’s Products
3 Glenlake Parkway
Atlanta, GA 30328
1-800-345-4109 • www.gracobaby
In Canada: Elfe Juvenile Products
4500 Thimens BLVD
Saint-Laurent, Quebec H4R 2P2
1-800-667-8184 • www.gracobaby.ca
