73
7 Moving
LATCH
2. Slide Entire LATCH Strap Along Bar
to Correct Belt Path Opening
Rear-Facing:
Slide LATCH strap down
to the blue label.
Forward-Facing:
slide the LATCH strap
up to the orange label.
3. Feed the LATCH Connector with the Adjuster Closest to it
Through the Chosen Belt Path
Rear-Facing: Make sure the LATCH strap is in front of the buckle strap when
the buckle is in the inner-most position (A), and in behind when in the outter-
most position (B) and that it is flat and is not twisted.
B
A
To Next Page
