15
{EN
INSTRUCTIONS}
Opening pushchair frame – see page 3, images 1, 2, 3
Basket – see page 3, images 4, 5, 6
Front Wheels – see page 3, image 7
Rear Axle – see page 4, images 1, 2
Child’s Tray or Bumper Bar – see page 4, images 3, 4, 5, 6
Rear Bumper Bar (on certain models) – see page 5, image 1, 2
Child’s Tray – see page 5, images 3, 4
Front Canopy - see page 5, images 5, 6, 7
Securing Your Child - 5 Point Harness – see page 6, images 1, 2, 3, 4, 5, 6
Adjusting Harness Height Position – see page 6, images 7, 8
Swivel Wheel Lock – see page 7, images 1, 2
Brakes – see page 7, image 3, 4
To raise and recline seats - see page 8, images 1, 2
Rear seat reclined carriage position - see page 8, images 3, 4
To Fold Pushchair– see page 9, images 1, 2, 3, 4
To Attach and Remove Graco® Click Connect™ Infant Car Seat
- see pages 10-11, images 1, 2, 3, 4, 5, 6, 7
