Graco Turn2Me i-Size - Height Adjustment

15
16

Press the release button to
remove side impact protection.
Height Adjustment
for Head Support and Shoulder
Harnesses
See images

-

Please adjust the head support
and check if the shoulder
harnesses are at the correct
height according to

.
When used rear facing, the
shoulder harness height must be
even with child’s shoulders.
When used forward facing, the
shoulder harness height must be
even with child’s shoulders.

Lift up the head support
adjustment lever

, meanwhile
pull up or push down on the
head support until it snaps into
one of the 6 positions. The head
support positions are shown as

.
Using in the Rear
Facing Mode
(Child height 40cm-105cm/Child
weight 19.5kg/infant - 4 years old)
See images

-

Please install the child restraint
on the rear vehicle seat, and
then put the child in the child
restraint.

Press the ISOFIX adjuster button
and pull the base back from the
vehicle seat.

Press the rotating button to
rotate for easier side loading/
unloading of the child, then
rotate back to desired direction.

If a tighter install or increased
cabin space is required, then
press the ISOFIX adjuster button
and push to adjust.

The ISOFIX connectors must be
attached and locked onto the
ISOFIX anchor points.
The load leg must be installed
correctly with green indicator.
After the child is placed into the seat,
check whether the Shoulder Harness
Straps are at proper height.

Press the webbing adjustment
button, while pulling out the
shoulder harnesses to the
proper length.

Unlock the buckle of the
harnesses by pressing the red
button.

Fix the buckles on the both
sides of seat to make placing the
child in rear facing mode more
convenient.
1
2
The cushion can be used separately
without being attached to the
insert to bolster the infant's back
for more comfort.
Remove the infant insert cushion
by detaching the snaps to allow
more space when the infant does
not fit comfortably.
Detach the snaps on the head
support to remove the head portion
of the insert.
We recommend using the full infant
insert while the baby is under 60cm
and can be used until they outgrow
the infant insert. The infant insert
increases side impact protection.
Remove the head support portion
of the infant insert when the child’s
head no longer fits comfortably.
Remove the body portion of the
infant insert when the infant’s
shoulders no longer fit comfortably.
1
2
The cushion can be used separately
without being attached to the
insert to bolster the infant's back
for more comfort.
Remove the infant insert cushion
by detaching the snaps to allow
more space when the infant does
not fit comfortably.
Detach the snaps on the head
support to remove the head portion
of the insert.
We recommend using the full infant
insert while the baby is under 60cm
and can be used until they outgrow
the infant insert. The infant insert
increases side impact protection.
Remove the head support portion
of the infant insert when the child’s
head no longer fits comfortably.
Remove the body portion of the
infant insert when the infant’s
shoulders no longer fit comfortably.

Use Infant insert is for children’s
protection.
