Models
3A0420V 13
Typ
eModel
Pump
Package
Volume
Mix
Ratio
7 Gallon
Hoppers
Mix
Manifold Hose Gun
Max Fluid
Working Pressure
psi (MPa, bar)
Max Hydraulic
Oil Working
Pressure
psi (MPa, bar)
Pressure
Ratio
XP-h with Viscount II
Hydraulic Motor
284104 284102 1:01
Standard
35 ft
(10.7 m)
XTR504
4700 (32, 324) 1800 (12, 124) 1:1
284204 284202 2:01 5050 (35, 348) 1800 (12, 124) 2:1
284254 284252 2.5:1 5000 (34, 345) 1650 (11, 114) 2.5:1
284304 284302 3:01 4700 (32, 324) 1800 (12, 124) 3:1
284404 284402 4:01 5000 (34, 345) 1800 (12, 124) 4:1
284106 284103 1:01
XTR704
7150 (50, 500) 1700 (12, 117) 1:1
284206 284203 2:01 7200 (50, 496) 1650 (11, 114) 2:1
284256 284253 2.5:1 6800 (47, 469) 1800 (12, 124) 2.5:1
284306 284303 3:01 7100 (49, 490) 1800 (12, 124) 3:1
284406 284403 4:01 7150 (49, 493) 1700 (12, 117) 4:1
