CONNECTION TO THE AMPLIFIER
Gradient Evidence is equipped with two pairs of binding
posts which are located on the base of the speaker. The
red marked plus terminals are linked together by a
jumper. The black marked minus terminals are similarly
connected to each other. The speaker can be connected
in the normal way as single-wired, bi-wired or bi-amped.
· normal or single-wiring
Connect the positive or plus lead from the amplifier to
one of the red binding posts of the speaker. In the same
way connect the ground lead or the negative lead from
the amplifier to one of the black binding posts. Connect
both speakers in the similar way. Check that the jumpers
between the similar binding posts are connected and
tightened.
· bi-wiring
For bi-wiring remove the jumpers between the binding
posts. Bi-wiring requires two pairs of loudspeaker cables
in parallel between the amplifier and the speaker. One
speaker cable drives the bass (LF+ and LF-) and the other
the midrange & treble of the speaker (HF+ and HF-).
5
