Graf 300 - General Notes; Safety Precautions; Technical Data

420
6001200
DN 100
DN 150
DN 100
DN 150
1.1 Safety
When working, the appropriate accident prevention regulations must be followed.
Furthermore, when carrying out assembly and installation work, inspection, maintenance and repairs,
all work regulations and norms must be followed.
The GRAF company offers an extensive range of accessories that are all compatible with one another
and may be used to construct a complete system. The use of other manufacturers accessories can
impair the function of the system and liability for any resulting damages will no longer be covered
under the guarantee.
Volume Gross 300 Litre Net 285 Litre
Length 1200 mm
Width 600 mm
Height 420 mm
Connections 12 x DN 150 + 6 x D 125 + 6 x DN 100
Weight Rain Bloc car: 15,5 kg
Rain Bloc car inspect: 16,5 kg
Rain Bloc lorry: 17,5 kg
Rain Bloc lorry inspect: 18,5 kg
Material Drainage block for HGV: 100 % Polypropylene (PP)
Drainage block for light traffic: 100 % Polypropylene (PP)
Recycling materials
2. Technical data
1. General notes
Page 6 of 8
