Follow the THROUGH WALL INSTALATION procedure for directions on how to
install the “wall flange “as described above.
1- Install the 5” to 6” galvanized adapter onto the Stoves 5” pipe that exits the stove.
2- Install either a 3 “ - 45 degree or 90 degree (whatever allows for the best configuration)
3” exhaust pipe.
3- Slide adjustable elbow pipe over the exhaust pipe and onto the 6” end of the galvanized
adapter.
4- Move stove to final position. In the final position, the stoves 5 inch pipe connector should
be slipped under Wall Thimble’s 6 inch pipe at least 1 inch.
BASEMENT INSTALLATION
Note: Extra piping will be needed for installing. Make sure 3” Diameter exhaust pipe is used
for exhausting. For bringing in Fresh air stove pipe (“A” type venting) may be used.
1- Follow the THROUGH WALL INSTALATION procedure for directions on how to
install the wall flange.
2- Take into account the height of the stove with the legs attached when calculating the
overall length of the piping assembly.
3- It is suggested to dry fit all items before cutting out the exit hole.
4- A 90 degree 3” exhaust pipe with a cleanout plug is required to facilitate the cleaning of
the fines and ash that build up (see cleaning procedure). This is attached to the exhaust
port coming out of the stove.
5- Slip on a 6” tee 90 degree over the 3” exhaust pipe, allowing for access to the cleanout
plug on the 90 degree 3” exhaust pipe.
6- Alternately assemble the 6” vent pipe and the 3” exhaust pipe to a level where the next 90
degree is to be made.
7- After the Flange assembly has been installed, slip a length of exhaust through the Flange
and mount the Muffler.
8- Slip a 90 degree 6” pipe over the 90 degree exhaust pipe and connect to the Flange
Assembly.
9- After making all adjustments, secure the outside exhaust pipe by screwing tight the clamp
in the Outer flange piece.
CHIMNEY VENT INSTALATION
If an existing chimney is used, these conditions must be met:
1- It must be inspected prior to use by your local building inspector.
10
