765042402 Rev. 000 31
The cabinet can be installed freestanding, against a wall or COMPACT 220 can be built
under a worktop.
The cabinet must have sufficient ventilation and free air circulation beneath, above and
behind the cabinet. There must be a minimum clearance of 30 mm above the cabinet, and
20 mm at the sides.
Fig. 5
• Correct set up gives the most effective operation.
• The product should be located in a dry and adequately ventilated room.
• To ensure efficient operation, it may not be placed in direct sunlight or against heat-
emitting surfaces. The product is designed to operate in an ambient temperature
between +16C and +30°C.
• Do not keep the door open for too long.
• Do not set the temperature setpoint too low.
• The product should be placed as close as possible up against the wall.
