Grammer MSG 90.6PG - 3.6 Bellows - removal and installation

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.6 Bellows – removal and installation
Page 1 of 5
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Bellows
(2) Lever for seat fore/aft adjustment
(3) Seat frame
(4) Lower suspension part
(5) Seat fore/aft adjustment
(6) Supporting structure (Actros, bus
seat)
(7) Bellows pin
(8) Cable tie
(9) Bowden pull wire for backrest
adjustment
(10) Cable tie
(11) Cable tie
(12) Bowden pull wire for fore/aft isolator
(13) Support
(14) Handle rail
