Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.21 Cable for electro-pneumatic gearshift (EPS) – removal and installation
Page 3 of 6
REMOVAL / INSTALLATION TABLE OF CONTENTS
5 Thread the EPS cable (1) through the
right covering (2).
6 Remove the entire covering
(Chapter 3.5).
7 Detach the EPS cable (1) at the two
spring clips (6).
8 Mark the point where the EPS cable
(1) is fastened to the seat frame (3) by
means of cable ties (4) and remove
the cable ties (4).
9 Bore out the rivet head and drive out
the blind rivet (7).
Note:
The rivet head must not be knocked
off.
1
1
6
2
6
4
1
6
6
4
2
1
3
9
8
7
2
1
4
5
3
