Grammer MSG 90.6PG - Page 249

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.29 Secondary belt – removal and installation
Page 2 of 3
REMOVAL / INSTALLATION TABLE OF CONTENTS
1 Lift off the seat cushion in position for
repair (Chapter 3.1).
2 Seat with operator console and
armrest for electro-pneumatic
gearshift:
Remove the clip for the EPS cable at
the lower suspension part (see
Chapter 3.21).
3 Remove the bellows at the rear of the
lower suspension part (see
Chapter 3.6).
Removal and installation
4 Unscrew the micro-encapsulated cap
screw (4).
Installation note:
Replace the micro-encapsulated cap
screw (4), 25 Nm.
2252
1
2
3
4
5 1
6
