Grammer MSG 90.6PG - 3.33 Lumbar support - removal and installation

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.33 Lumbar support – removal and installation
Page 1 of 5
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Backrest
(2) Safety belt
(3) Backrest cover
(4) Foam plastic part
(5) Lumbar support
(6) Lattice frame
(7) Air hose for upper chamber
(8) Air hose for lower chamber
(9) Hose connector
(10) Zipper
(11) Covering clamps ................. replace
