Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.38 Level control – removal and installation
Page 1 of 6
(1) Level control
(2) Swinging structure
(3) Lock washer
(4) Centre axle (swinging structure)
(5) Front axle, bottom (swinging
structure)
(6) Clamp, right (level control)
(7) Clamp, left (level control)
(8) Bracket (level control)
(9) Air hose (blue) to the air spring (Z)
(10) Air hose (black) for air intake (P)
(11) Air hose (gray) for air exhaust (R)
(12) Air spring
3
5
4
2
6
7
8
1
R
P
Z
9
11
10
4
1
3
6
7
1
0
8
1
1
5
9
2
P
R
Z
1
2
9
8
11
10
Z
12
1
P
R
6
Z
2239
