Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.38 Level control – removal and installation
Page 3 of 6
1 Lift off the seat cushion in position for
repair (Chapter 3.1).
2 Remove the left covering in position
for repair (Chapter 3.4).
3 Detach the front covering at the right
covering (see Chapter 3.5).
4 Remove the bellows at the front of the
upper suspension part (see
Chapter 3.6) and press it down.
5 Detach the Bowden pull wire for quick
lowering of the seat at the level control
(retainer and valve lever) (see
Chapter 3.7).
6 Hang out the Bowden pull wire for
seat height adjustment at the level
control (control disc) (see
Chapter 3.9).
3
5
4
2
6
7
8
1
R
P
Z
9
11
10
4
1
3
6
7
1
0
8
1
1
5
9
2
P
R
Z
1
2
9
8
11
10
Z
12
1
P
R
6
Z
2239
