Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.38 Level control – removal and installation
Page 4 of 6
7 Remove the cable for vehicle
connection at the level control (see
Chapter 3.20).
8 Remove the air hose for lumbar
support and lateral support adjustment
at the retainer of the level control (see
Chapter 3.22).
9 Pull the air hose out of the air spring
(see Chapter 3.36).
10 Pull out the air hose at the air spring
support (see Chapter 3.22).
11 Remove the air hoses for the air
spring, air intake and air exhaust at
the level control (see Chapter 3.22).
3
5
4
2
6
7
8
1
R
P
Z
9
11
10
4
1
3
6
7
1
0
8
1
1
5
9
2
P
R
Z
1
2
9
8
11
10
Z
12
1
P
R
6
Z
2239
