Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.43 Seat frame – removal and installation
Page 1 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Seat frame
(2) Stud ................................. to grease
(3) Blind rivet
(4) Support
(5) Blind rivet
(6) Rounded head screw
(inner race) ............................. 3 Nm
(7) Protective profile
(8) Clip (for cable and Bowden pull
wire)
(9) Z-section
(10) Blind rivet
(11) Guide ............................... to grease
(12) Upper suspension part
(13) Clearance spacer
(14) Slider
F
F
F
F
F
F
2
1
7
21
13
12
22
5
19
18
4
2
5
3
6
13
6
4
17
17
3
11
11
11
11
14
14
15
16
9
9
10
10
8
8
8
8
10
10
18
2248
9
1
1
8
20
10
10
