Grammer MSG 90.6PG - Page 7

November 2017
Material no. 1153450_c
Repair Manual GRAMMER Seat MSG 90.6PG Commercial Vehicles, Omnibuses
Page 7 of 7
END
TABLE OF CONTENTS
3.48 Bowden pull wire and bearing for ideal backrest adjustment – removal and installation
3.49 Cable harness for backrest – removal and installation (seat with climate control system)
3.50 Cable harness heater switch – removal and installation (seat with climate control system)
3.51 Cable harness for vehicle connection – removal and installation (seat with climate control system)
3.52 Radial fan for backrest – removal and installation (seat with climate control system)
3.53 Control module for climate control system – removal and installation (seat with climate control system)
3.54 Cable harness for microphone – removal and installation (seat with climate control system)
3.55 Microphone support – removal and installation (seat with climate control system)
3.56 Play in the backrest locking mechanism – inspection and adjustment
