POE
Power Supply for
Electric Strike
DC 6-24V
GDS3710
POE Switch
V-
V+
IN1+
IN1-
Door lock Switch
COM2
NO2
NC2
IN2+
IN2-
“Fail Safe” Model
Electric Strike
COM1
NO1
POE
Eth
Eth
Eth
Eth
Cat 5e/6 Ethernet Cable
Outdoors
Indoors
GDS3710 Connection & Wiring Diagrams ---- “Fail Safe” Electric Strike, 3
rd
Party Power Supply + POE
Oponal
Oponal
