Grandstream Networks GDS3710 Quick Reference Guide

.9. .10.
(1)
(2)
(3)
(4)
PA3.5*35mm
PM3*10mm
PM3*12mm
M3
Step 4: Use provided Screws and Nuts(3)(4)
to install the
Plastic Box on the long edge of the Metal Frame.
Choose either set of Nuts(4) with convenience.
or
Step 3: Mount the Installation Bracket into the Plastic Box
using supplied Screws(2).
Step 2: Install the Metal Frame with short edge to the stud
using the set of Anchor/Screw(1) provided.
35mm
(or 1.38 inch)
Stud Installation
Please follow below steps to install the device at the stud of
a new building open wall,or a finished wall.
Step 1: For finished wall, use provided Drill Template to
mark boundary and dig a rectangle hole into the
wall. For open wall, skip and go to next step.
Max: 203.2 mm(or 8 inch)
