Grandstream Networks GWN7664LR User Manual

~ 1 ~ ~ 2 ~
OVERVIEW
The GWN7664LR is an outdoor 802.11ax 4×4:4 Wi-Fi 6 access point
for medium-to-large business and enterprises who need to provide
long-range coverage in both indoor and outdoor spaces. It offers
weatherproof casing and heat resistant technology, dual-band 4×4:4
MU-MIMO with DL/UL OFDMA technology and a sophisticated
antenna design for maximum network through that supports 512
clients and an expanded 300-meter coverage range. To ensure easy
installation and management, the GWN7664LR includes a built-in
controller embedded within the product’s web user interface. It is
also supported by GWN.Cloud and GWN Manager, Grandstream’s
free cloud and on-premise Wi-Fi management platform. The
GWN7664LR is the ideal Wi-Fi AP for voice-over Wi-Fi deployment
and offers a seamless connection with Grandstream’s Wi-Fi capable
voice and video IP phones. With support for advanced QoS,
low-latency real-time applications, mesh networks, captive portals
and dual Gigabit networks ports with PoE/PoE+, the GWN7664LR is
an ideal outdoor Wi-Fi access point for enterprises, multiple floor
offices, warehouses, hospitals, schools and more.
PRECAUTIONS
• Do not attempt to open, disassemble, or modify the device.
• Do not expose this device to temperature outside range of -30 °C to 60 °C for
operation and -30 °C to 60 °C for storage.
• Do not expose the GWN7664LR to environments outside of the following
humidity range: 10-90% RH (non-condensing).
• Do not power cycle your GWN7664LR during system boot up or firmware
upgrade. You may corrupt firmware images and cause the unit to malfunction.
PAKEAGE CONTENTS
GWN7660 PORTS
Port
Description
NET/POE
2.5G
Ethernet RJ45 port (10Mbps /100Mbps /1Gbps
/2.5Gbps) supporting PoE/PoE+.
NET/POE
1G
Ethernet RJ45 port (10Mbps/100Mbps/1Gbps) to your
router or another GWN76xx, support PoE/PoE+.
RESET
Factory reset button.
Press for 7 seconds to reset factory default settings.
POWERING AND CONNECTING THE GWN7664LR
GWN7664LR can be powered on using PoE/PoE+ switch using
following steps.
Step 1: Plug a RJ45 Ethernet cable into the network port of
GWN7664LR.
Wall
EN
1x GWN7664LR
Access Point
4x Antennas
1x Base
Bracket
4x Screw
(PM 3.0x7)
4x Screw
Anchors
4x Screws
(PA 3.5 x 33)
2x Metal
Straps
1x Quick
Installation
Guide
