HT70X User manual
Version 1.0.9.4
Port Status
Displays relevant information regarding the FXS port.
Port
Hook
Registration
DND
Forward
Busy
Forward
Delayed
Forward
FXS
On Hook
Registered
Yes
613
• FXS port is registered with SIP Server.
• FXS Port user has set Do Not Disturb.
• FXS Port user has set his calls to be unconditionally forwarded to ext 613.
• FXS Port user has not set Busy or Delay call Forward.
Log in to the advanced user configuration page the same way as for the basic configuration page. The
password is case sensitive and the factory default password for Advanced User is “admin”.
Advanced User configuration includes the end user configuration and the advanced configurations including:
a) SIP configuration, b) Codec selection, c) NAT Traversal Setting and d) other miscellaneous configuration.
HT701 and HT702 FXS SIP account(s) have its own configuration page. HT704 has two (2) profiles for the
four (4) FXS ports.
Table 10: Advanced Settings
Admin Password
This contains the password to access the Advanced Web Configuration page. This
field is case sensitive. Only the administrator can configure the “Advanced
Settings” page. Password field is purposely left blank for security reasons after
clicking update and saved. The maximum password length is 25 characters.
Layer 2 QoS
Set values for :
802.1Q/VLAN Tag (0-4094)
SIP 802.1p (0-7)
RTP 802.1p (0-7)
STUN Server is
IP address or Domain name of the STUN server.
Keep-alive interval
This parameter specifies how often the HT70X sends a blank UDP packet to the
SIP server in order to keep the “hole” on the NAT open. Default is 20 seconds.
Minimum value is 20 seconds.
