Parts list
No. Description Quantity No. Description Quantity
1 Bolt M6 x 55 4 33 Motor cover 1
2 Cylinder head 1 34 Boltw M5 x 103 4
3 Air filter 1 35 Fan 1
4 Cylinder head gasket 1 36 Circlip 1
5 Valve plate 2 37 Connector 1
6 Clack valve 2 38 Fan cover 1
7 Aluminium gasket 1 39 Nut M8 1
8 Valve plate gasket 1 40 Washer 1
9 Cylinder 1 41 Capacitor 1
10 Hex bolt M8 x 25 2 42 Rubber washer 4
11 Cylinder gasket 1 43 Valve (1-way) 1
12 Piston ring 1 44 Release pipe 1
13 Piston 1 45 Bolt M5 x 14 6
14 Piston pin 1 46 Discharge pipe 1
15 Piston pin circlip 2 47 Nut M10 2
16 Bolt M5 x 16 4 48 Spring 2
17 Crank case cover 1 49 Washer 2
18 Indicator gasket 1 50 Wheel 2
19 Oil level indicator 1 51 Wheel 2
20 Bolt M6 x 10 1 52 Bolt M10 2
21 Circlip 1 53 Stanchion 1
22 Rubber gasket 1 54 Air tank 1
23 Connecting rod 1 55 Stem 2
24 Hex bolt M8 x 22 (LH) 1 56 Nut 1
25 Crank 1 57 Power cable 1
26 Crankcase 1 58 Wire 1
27 Sealing ring 1 59 Safety valve 1
28 Bearing 1 60 Pressure gauge 2
29 Stator 1 61 Regulator gauge 2
30 Rotor 1 62 Quick coupling 1
31 Bearing 1 63 Regulator valve 1
32 Shaft washer 1 64 Pressure switch 1
10. Scope of delivery
No. Description Quantity
1 Air compressor 1
2 Air filter 1
3 Breath pipe 1
4 Rubber gasket 1
5 Instruction manual 1
