3.2 Rearpanelreferenceanddescription(seeFig3)
IECoutlettoaccessorypump.
IECoutlettoOptima Thermostatunit.
IECinlettoRefrigerationunitwithintegraltwinfusedraw.
Communicationslinksocket. Therefrigerationunitmaybecontrolledwithan
OptimaGR150orGP200thermostatunit. Thisisdonebylinkingthe
thermostattotherefrigeratorwiththecommunicationsleadsupplied.(Seespecific
examplesinsection4)
FuseprotectionfortheCommunicationsLead.
Mainsinputcable.
Mainsinputfuseholders.
FUSE
250mA(T)
5
4
3
1
FUSE
250mA(T)
5
4
2
3
1
1
2
3
Fig3a
R1
Fig3b
R2/R3
Fig3c
R4/R5
Page9
Lowtemperaturebath/circulator
Operatinginstructions
Version4-Jan2010
