Grant Vortex 26/36 - Boiler Dimensions; Kitchen and Kitchen System 15;26 Dimensions; Utility and Utility System 15;26 Dimensions

9
Grant Vortex Oil Boilers
FRONT VIEW
470
860
LEFT SIDE VIEW
813
759
709
487
587
352
18
17
110
30
Flue centre line
RIGHT SIDE VIEW
631
59
PLAN VIEW
470
603
110
22mm condensate drain
Safety valve
Cold fill
Flow - 22mm push-fit
22mm stainless
return
170
Flue
spigot
3 - BOILER TECHNICAL INFORMATION
Boiler dimensions
3.4
Fig 1a - Kitchen and Kitchen System 15/26 dimensions
Fig. 1b - Utility and Utility System 15/26 dimensions
