5
QuickStart Setup
Then connect the MC4 outputs of the 15-foot cables to the 6” MC4-to-bare wire pair as shown below:
Step 7: Connect the bare wire end of the red cable to the “PV Positive” input of the controller, and the black
cable end to the “PV Negative” input (the left hand set of terminals).
GS-300-KIT EXPANDABLE PHOTOVOLTAIC
POWER GENERATION SYSTEM
CONFIGURATION MANUAL Rev. 180601
Valid from June 2018
