Graphite 58G020 - Page 15

15
• Clean ventilation holes in the motor casing regularly to
prevent device overheating.
• Always store the tool in a dry place, beyond reach of children.
• Store the device with the battery removed.
QUICK RELEASE CHUCK REPLACEMENT
Quick-release chuck is screwed onto spindle of the drill and
additionally secured with a screw.
• Set the direction selector switch (5) in the middle position.
• Open jaws of quick release chuck (1) and unscrew the fixing
screw (left-hand thread) (fig. H).
• Install hexagonal key in the quick release chuck and tap the
other end of the key.
• Unscrew the quick release chuck.
• Installation of the quick release chuck is similar to
deinstallation, only the sequence of actions is reversed.
All defects should be repaired by service workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless drill with impact 58G020
Parameter Value
Battery voltage 18 V DC
Range of idle rotational speed
gear I 0-500 min
-1
gear II 0-1700 min
-1
Impact speed on idle
gear I 0-7500 min
-1
gear II 0-25500 min
-1
Range of quick release chuck 2-13 mm
Torque control range
1–16 + drilling,
impact drilling
Max. torque (soft drive) 38 Nm
Max. torque (hard drive) 58 Nm
Protection class III
Weight 1,2 kg
Year of production 2018
58G020 denes type and indication of the device
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2018 2018
Graphite Energy+ System Charger
Parameter Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2018
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure (drilling) Lp
A
= 77,5 dB(A) K= 3 dB(A)
Sound pressure (drilling with
impact)
Lp
A
= 85,5 dB(A) K= 3 dB(A)
Sound power (drilling) Lw
A
= 88,5 dB(A) K= 3 dB(A)
Sound power (drilling with
impact)
Lw
A
= 96,5 dB(A) K= 3 dB(A)
Vibration acceleration (drilling) a
h
= 2,04 m/s
2
K= 1,5 m/s
2
Vibration acceleration (drilling
with impact)
a
h
= 11,72 m/s
2
K= 1,5 m/s
2
Noise and vibration information
Noise produced by the device is defined with: level of produced
sound pressure Lp
A
and level of sound power Lw
A
(where K is
measurement uncertainty). Vibrations produced by the device
are defined with vibration acceleration value a
h
(where K is
measurement uncertainty).
Sound pressure Lp
A
, sound power Lw
A
and vibration acceleration
ah specified in this manual have been measured in accordance
with EN 60745-1. Specified vibration level a
h
can be used
to compare tools and for initial evaluation of exposition to
vibrations.
Specified vibration level is representative for main applications
of the device. When the device is used for other purposes or
with different working tools, the vibration level may change.
Insufficient or too rare maintenance may increase vibration
level. The abovementioned factors may lead to higher exposure
to vibrations during whole working time.
To precisely define exposure to vibrations, include periods
when the device is switched off and when it is switched on
but not used for working. Once all factors have been carefully
considered, total exposition to vibrations may be significantly
lower.
To protect the user from results of exposure to vibrations, use
additional safety measures such as: device and working tool
periodic maintenance, proper hand temperature conditions,
good work organisation.
