Graphite 58G529 - Operation and Maintenance; Technical Parameters

18
OPERATION AND MAINTENANCE
Unplug the power cord from mains socket before commencing any activities related to installation,
adjustment, repair or maintenance.
MAINTENANCE AND STORING
•
Cleaning the device after each use is recommended.
•
Do not use water or any other liquid for cleaning.
•
Do not use any cleaning agents or solvents, they may damage plastic parts.
•
Clean the tool with a dry cloth or blow with compressed air at low pressure.
•
Clean ventilation holes in the motor casing regularly to prevent device overheating.
•
In case of excessive commutator sparking, have the technical condition of carbon brushes of the motor
checked by a qualied person.
•
In case of power cord damage replace it with a cord with the same specication. Entrust the repair to a
qualied specialist or return the tool to a service point.
•
Always store the tool in a dry place, beyond reach of children.
REPLACEMENT OF CARBON BRUSHES
Immediately replace worn out (shorter than 5 mm), burnt or cracked motor carbon brushes. Always
replace both carbon brushes at a time.
Entrust replacement of carbon brushes only to a qualied person. Only original parts should be used.
All defects should be repaired by service workshop authorized by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Rotary Hammer
Parameter Value
Supply voltage 230 V AC
Power supply frequency 50 Hz
Rated power 800 W
Rotational speed 0-1200 min
-1
Impact rate 0 - 5300 min
-1
Impact energy 3,2 J
Working tool shank SDS Plus
Maximum drilling diameter
concrete 28 mm
steel 13 mm
wood 30 mm
Protection class II
Weight 3,2 kg
Year of production 2021
NOISE AND VIBRATION DATA
Information regarding noise and vibration
The following levels of emitted noise, such as emitted acoustic pressure Lp
A
and acoustic power level Lw
A
and measurement uncertainty K have been given in the instruction manual as dened in the EN 60745
standard.
The following vibration value (acceleration value) a
h
and measurement uncertainty K have been determi-
ned as dened in the EN 60745-2-6 standard.
The vibration level provided in this instruction manual have been determined according to the measure-
