ORIGINAL MANUAL (INSTRUCTION)
ELECTRIC PLANER
59G680
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL CAREFULLY AND KEEP IT FOR FUTURE
REFERENCE.
DETAILED SAFETY REGULATIONS
SPECIAL CONDITIONS REGARDING SAFETY OF ELECTRIC PLANER OPERATION
Before connecting the planer to mains socket make sure the supply voltage matches the voltage on ●
the rating plate of the tool.
Connect the planer only to electrical system equipped with residual current circuit breaker that will cut ●
the power off when earth leakage current exceeds 30 mA in less than 30 ms.
Use only sharp cutting parts. ●
After the work has been finished and before putting the planer away wait until rotating parts stop ●
completely.
Use hearing protection measures when working with planer. ●
When using the planer hold it firmly with both hands. ●
Power cord of the planer must be on the safe side, where there is no danger of accidental damage by ●
operating power tool.
Before starting operation ensure there are no metal objects, such as nails or screws, in the processed ●
material.
Do not put fingers into dust outlet hole. Clean the outlet with a piece of wood. ●
Fix processed material to prevent it from slipping. ●
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and additional safety systems are used,
nevertheless there is always a small risk of operational injuries.
CONSTRUCTION AND USE
Planer is a hand-held power tool with insulation class II. The tool is driven by single-phase commutator
motor. Planer is designed for processing wooden surfaces.
Range of use covers repair and building works, woodworking and any work from the scope of individual,
amateur activities (tinkering).
Use the power tool according to the manufacturer’s instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
Knob for planing depth adjustment1.
Switch2.
Switch lock button3.
Drive belt cover4.
Dust extraction outlet5.
Front footplate6.
Planing depth scale7.
Parallel guide position locking wheel8.
Parallel guide9.
Deep planing guide12.
Locking knob for deep planing guide13.
Guide handle14.
Fixing screws 15.
Blade 16.
